FSE – Fall safety independent bars for access cover PT, KT
Safety for field operators when access hatches are open.
Stainless steel safety grids made out solidary bars are designed to prevent people from falling into underground structures such as telecom chambers, wastewater lift chambers, valve chambers, etc. Each bar of the safety grid can be operated separately. Only the bars in contact with the element to be lifted will be operated. The rest of the access to the structure remains secure.
Place of use
On all versions of PT and KT access hatches.
1 hinged grid per lid on the same side as the covers, for unobstructed opening and preserved access to the structure.
Material
Stainless Steel AISI 304L low carbon
Remarks
Stainless steel safety grids offering high resistance in agressive atmospheres.
Drawings and dimensions
