KEOPS grating 250kn
Enlarge image

KEOPS grating 250kn

Product description

The KEOPS grating 250 kN is particularly recommended for all surface drainage systems located in the roadside areas of freeways and link roads. Available in cast-iron and steel versions.

Material

Grating and Frame: Spheroidal cast iron / Steel.
Polyester coating.

Options

Theft protection lock.

Product description
Product description

Drawings and dimensions

Table and references

Code
Material
C (mm)
H (mm)
O (mm)
Absorption surface (dm2)
A (mm)
e (mm)
Grating (kg)
Frame (kg)
Add in the wishlist
15785
Cast iron
470
38
380
8
400
96
12
5.6

15786
Steel
514
30
414
13
500
120
22.5
8.4

15784
Steel
814
30
714
34
810
130
39.5
10
