Recessed infill manhole cover LTR C250
Equipped with a recessed tray made of cast iron and a steel frame in C250, LTR recessed infill access cover range is designed for installation on dry networks chambers such as telecom or fiber optic networks, or on underground structures.
Place of use
C250 : For gully tops installed in the area of kerbside channels of roads which when measured from the kerb edge, extend a maximum of 0,5m into the carriageway and a maximum of 0,2m into the footway.
Certification
Complies with the requirements of EN-124-2 standard. Third-party certified with TÜV SÜD Industrie Service GmbH mark.
Material
Hatch Cover(s) – Spheroidal cast iron EN-GJS-500-7.
Finished by water based black paint, environmentally friendly.
Hatch Frame – Steel hot-dip galvanized,
average thickness 90µm according to ISO 1461.
Options
Handling tools.
Remark
Delivered without concrete
Layer height : 48 mm
Drawings and dimensions
